To see if LGU is compatible with your computer, please download and run our compatibility test tool.
Specifications
| Connections | ||
|---|---|---|
| Interface | USB 3.1 Type C (UVC) | |
| Video Input | Digital: HDMI 2.0 | |
| Audio Input | Digital: HDMI 2.0 | |
| Video Output | Digital: HDMI (Pass-through from HDMI Input) | |
| Audio Output | Digital: HDMI (Pass-through from HDMI Input) | |
| Standards | ||
| Resolution | Input/ Pass-through: 3840 x 2160 (60, 59.94, 50, 30, 29.97, 25, 24p), 2560 x 1440 (144, 120, 60, 59.94p), 2560 x 1080 (144, 120, 60, 59.94p), 1920 x 1080 (240, 144, 120, 60, 59.94, 50, 30, 29.97, 25, 24p; 60, 59.94, 50i), 1280 x 720 (60, 59.94, 50), 720 x 576 (50p, 50i), 720 x 480 (60, 59.94p; 60, 59.94i), 640 x 480 (60p) Recording: 3840 x 2160 (30, 29.97, 25p), 2560 x 1440 (60, 50, 30p), 2560 x 1080 (60, 30p), 1920 x 1080 (120, 60, 59.94, 50, 30, 29.97, 25p), 1280 x 720 (60, 59.94, 50, 30, 29.97, 25), 720 x 576 (50, 25p), 720 x 480 (60, 59.94, 30, 29.97), 640 x 480 (60, 30p) HDR Recording: 1920 x 1080 (60, 59.94, 50, 30, 29.97, 25p), Note: Upscaling is not supported |
|
| Chroma Subsampling | Input/ Pass-through: YUV 4:4:4 Capture: YUV 4:2:2 or RGB24 (FHD) Record: YUV 4:2:0 |
|
| Audio Format | Input:HDMI: Stereo Capture:HDMI: Stereo |
|
| Applications | ||
| Software | AVerMedia RECentral Installing RECentral will automatically install “Stream Engine”. This plug-in will virtually remove any out-of-sync-audio situation you might encounter while using any 3-party streaming software . Please select “AVerMedia Live Gamer Ultra-Video Audio Stream Engine” in the audio settings of your preferred 3-party streaming software. |
|
| Record Quality | Maximum: 240Mbps@4Kp30 | |
| Operating System | Windows 10 (64bits) (Support UVC Protocol) MacOS High Sierra 10.13 |
|
| CPU | For 4Kp30 or 1080p120: • Desktop: Intel® Core™ i5-6XXX or above • Laptop: Intel Core i7-7700HQ or above For 1080p60 : • Desktop: Intel® Core™ i5-4440 3.10 GHZ or above (i7-3770 recommended) • Laptop: Intel Core i7-4810MQ + NVIDIA® GeForce® GTX 870M or above For Mac: For 4Kp30 or 1080p120: • iMac: 3.6GHz quad-core Intel Core i7 • Macbook Pro: 2.8GHz quad-core Intel Core i7 For 1080p60 : • iMac: 3.6GHz quad-core Intel Core i7 • Macbook Pro: 2.6GHz quad-core Intel Core i7 |
|
| Memory | For 4Kp30 or 1080p120: 8 GB RAM (Dual-channel) For 1080p60 : 4 GB RAM (8GB Recommended) For Mac: For 4Kp30 or 1080p120: • iMac: 16GB of 2400MHz DDR4 memory • Macbook Pro: 16GB 2400MHz DDR4 memory For 1080p60 : • iMac: 16GB of 2400MHz DDR4 memory • Macbook Pro:16GB of 2133MHz LPDDR3 onboard memory |
|
| Graphics Card | For 4Kp30 or 1080p120: • Desktop: NVIDIA® GeForce® GTX 1060 or above • Laptop: NVIDIA® GeForce® GTX1050 Ti or above For 1080p60 : • Desktop: NVIDIA® GeForce® GTX 660 / AMD Radeon™ R7 250X or above are recommended • Laptop: NVIDIA® GeForce® GTX 870M or above For Mac: For 4Kp30 or 1080p120: • iMac:Radeon Pro 555 with 2GB of VRAM • Macbook Pro: Radeon Pro 555X with 4GB of GDDR5 memory For 1080p60 : • iMac: Radeon Pro 555 with 2GB of VRAM • Macbook Pro: Radeon Pro 450 with 2GB of GDDR5 memory |
|
| Package Includes | ||
| Device | Live Gamer Ultra (GC553) | |
| Cable | HDMI 2.0 cable Type C to Type A Cable |
|
| Others | 1. Quick guide 2. CyberLink PowerDirector 15 Product Key Card* *4K video editing software |
|
- Technical Specifications
- • Interface:USB 3.1 (Gen 1) Type C
• Video Input:HDMI 2.0
• Video Output (Pass-Through):HDMI 2.0
• Audio Input:HDMI 2.0
• Audio Output (Pass-Through):HDMI 2.0
• Max Pass-Through Resolutions:2160p60 HDR /1440p144 / 1080p240
• Max Record Resolutions:2160p30 / 1440p60 / 1080p120 / 1080p60 HDR
• Supported Resolutions (Video input):2160p, 1440p, 1080p, 1080i, 720p, 576p, 480p
• Record Format:MPEG 4 (H.264+AAC) or (H.265+AAC)*
• Dimension (W x D x H):112.6 x 66.2 x 26 mm (4.43 x 2.6 x 1.02 in)
• Weight:116 g (4.09 oz.)
Notes:
*H.265 Compression and HDR are supported by RECentral
1. LGU does not support viewing/recording/streaming of HDCP protected signals
- System Requirements(For dedicated streaming PC)
- Operating sytem: Windows® 10 x64 (Support UVC Protocol)For 4Kp30 or 1080p120 (4Kp60 HDR pass-through supported)Desktop:Intel® Core™ i5-6XXX or above
NVIDIA® GeForce® GTX 1060 or above
8 GB RAM (Dual-channel)
Laptop:Intel Core i7-7700HQ or above
NVIDIA® GeForce® GTX1050 Ti or above
8 GB RAM (Dual-channel)
For 1080p60 (4Kp60 HDR pass-through supported)Desktop:Intel® Core™ i5-4440 3.10 GHz or above
NVIDIA® GTX 660
4 GB RAM (8 GB recommended)
Laptop:Intel Core i7-4810MQ
NVIDIA® GeForce® GTX 870M or above
4 GB RAM (8GB Recommended)
Mac system requirement :Operating system: MacOS High Sierra 10.13Mac Thunderbolt 3 (USB‑C) Cable (0.8 m)
For 4Kp30 or 1080p120 (4Kp60 HDR pass-through supported)iMac:3.6GHz quad-core Intel Core i7
Radeon Pro 555 with 2GB of VRAM
16GB of 2400MHz DDR4 memory
MacBook Pro:2.8GHz quad-core Intel Core i7
Radeon Pro 555X with 4GB of GDDR5 memory
16GB 2400MHz DDR4 memory
For 1080p60 (4Kp60 HDR pass-through supported) :iMac:3.6GHz quad-core Intel Core i7
Radeon Pro 555 with 2GB of VRAM
16GB of 2400MHz DDR4 memory
MacBook Pro:2.6GHz quad-core Intel Core i7
Radeon Pro 450 with 2GB of GDDR5 memory
16GB of 2133MHz LPDDR3 onboard memory
Notes:
1. LGU does not support USB 2.0
2. LGU does not support USB 3.1 Gen 2
3. We strongly recommended to use Intel chipset.
4. For 4K, HDR or High frame rate recording only NVIDIA graphics card are supported.
- What’s in the box
- • Live Gamer Ultra (GC553)
• HDMI 2.0 cable
• Type C to Type A Cable
• Quick guide
• CyberLink PowerDirector 15 Product Key Card* Notes:
*4K video editing software. Does not support HEVC encoded files or HDR editing. Please note that this version of PowerDirector 15 is not the retail version and some functionalities may be restricted or require paid upgrades.
